Split Type Dial Bore Gauges
Code: 2426
Split type contact points
Optional accessory: digital/dial indicators or dial comparator
Specification
| Code | Range | Accuracy | Repeatability |
|---|---|---|---|
| 2426-1 | 0.95-1.15mm | 3µm | 1µm |
| 2426-1D1 | 1.07-1.25mm | 3µm | 1µm |
| 2426-1D2 | 1.17-1.35mm | 3µm | 1µm |
| 2426-1D3 | 1.27-1.45mm | 3µm | 1µm |
| 2426-1D4 | 1.37-1.55mm | 3µm | 1µm |
| 2426-1D75 | 1.5-1.9mm | 3µm | 1µm |
| 2426-2 | 1.8-2.2mm | 3µm | 1µm |
| 2426-2D25 | 2.05-2.45mm | 3µm | 1µm |
| 2426-2D5 | 2.3-2.7mm | 3µm | 1µm |
| 2426-2D75 | 2.55-2.95mm | 3µm | 1µm |
| 2426-3 | 2.8-3.2mm | 3µm | 1µm |
| 2426-3D25 | 3.05-3.45mm | 3µm | 1µm |
| 2426-3D5 | 3.3-3.7mm | 3µm | 1µm |
| 2426-3D75 | 3.55-3.95mm | 3µm | 1µm |
| 2426-4 | 3.8-4.2mm | 3µm | 1µm |
| 2426-4D5 | 4.15-4.8mm | 3µm | 1µm |
| 2426-5 | 4.7-5.3mm | 3µm | 1µm |
| 2426-5D5 | 5.2-5.8mm | 3µm | 1µm |
| 2426-6 | 5.7-6.3mm | 3µm | 1µm |
| 2426-6D5 | 6.2-6.8mm | 3µm | 1µm |
| 2426-7 | 6.7-7.3mm | 3µm | 1µm |
| 2426-7D5 | 7.2-7.8mm | 3µm | 1µm |
| 2426-8 | 7.7-8.3mm | 3µm | 1µm |
| 2426-8D5 | 8.2-8.8mm | 3µm | 1µm |
| 2426-9 | 8.7-9.3mm | 3µm | 1µm |
| 2426-10 | 9.2-10.5mm | 3-4µm | 1µm |
| 2426-11 | 10.2-11.5mm | 4µm | 1µm |
| 2426-12 | 11.2-12.5mm | 4µm | 1µm |
| 2426-13 | 12.2-13.5mm | 4µm | 1µm |
| 2426-14 | 13.4-14.6mm | 4µm | 1µm |
| 2426-15 | 14.4-15.6mm | 4µm | 1µm |
| 2426-16 | 15.4-16.6mm | 4µm | 1µm |
| 2426-17 | 16.4-17.6mm | 4µm | 1µm |
| 2426-18 | 17.4-18.6mm | 4µm | 1µm |
| 2426-19 | 18.4-19.6mm | 4µm | 1µm |
| 2426-20 | 19.4-20.6mm | 4µm | 1µm |
