Indicating Micrometers
Code: 3333
Meet DIN863-3
Carbide measuring faces
Measuring force 5-10N
Dial can be adjusted
Specification
| Code |
Range |
Graduation |
Dial indicator range |
Dial indicator graduation |
| 3333-25 |
0-25mm |
0.01mm |
±0.07mm |
1μm |
| 3333-252 |
0-25mm |
0.01mm |
±0.14mm |
2μm |
| 3333-50 |
25-50mm |
0.01mm |
±0.07mm |
1μm |
| 3333-502 |
25-50mm |
0.01mm |
±0.14mm |
2μm |
| 3333-75 |
50-75mm |
0.01mm |
±0.07mm |
1μm |
| 3333-752 |
50-75mm |
0.01mm |
±0.14mm |
2μm |
| 3333-100 |
75-100mm |
0.01mm |
±0.07mm |
1μm |
| 3333-1002 |
75-100mm |
0.01mm |
±0.14mm |
2μm |
| 3333-125 |
100-125mm |
0.01mm |
±0.07mm |
1μm |
| 3333-1252 |
100-125mm |
0.01mm |
±0.14mm |
2μm |
| 3333-150 |
125-150mm |
0.01mm |
±0.07mm |
1μm |
| 3333-1502 |
125-150mm |
0.01mm |
±0.14mm |
2μm |
| 3333-175 |
150-175mm |
0.01mm |
±0.14mm |
2μm |
| 3333-200 |
175-200mm |
0.01mm |
±0.14mm |
2μm |
| 3333-225 |
200-225mm |
0.01mm |
±0.14mm |
2μm |
| 3333-250 |
225-250mm |
0.01mm |
±0.14mm |
2μm |
| 3333-275 |
250-275mm |
0.01mm |
±0.14mm |
2μm |
| 3333-300 |
275-300mm |
0.01mm |
±0.14mm |
2μm |
