Tubular Inside Micrometers
Code: 3684
Micrometer head: 50-75mm
Carbide measuring faces
Specification
| Code |
Range |
Accuracy |
Graduation |
| 3684-75 |
50-75mm |
5μm |
0.01mm |
| 3684-100 |
50-100mm |
5μm |
0.01mm |
| 3684-150 |
50-150mm |
6μm |
0.01mm |
| 3684-250 |
50-250mm |
8μm |
0.01mm |
| 3684-300 |
50-300mm |
9μm |
0.01mm |
| 3684-350 |
50-350mm |
10μm |
0.01mm |
| 3684-450 |
50-450mm |
10μm |
0.01mm |
| 3684-650 |
50-650mm |
12μm |
0.01mm |
| 3684-850 |
50-850mm |
15μm |
0.01mm |
| 3684-1250 |
50-1250mm |
20μm |
0.01mm |
| 3684-1450 |
50-1450mm |
22μm |
0.01mm |
