Digital Rtj Ring Groove Calipers
Code: 1179
Non waterproof
Angle of RTJ ring groove: 23°
Measure ring grooves of flange
Button function: on/off, set, zero, mm/inch, data preset
Battery CR2032
Made of stainless steel
Specification
| Code | Range | Accuracy | Resolution |
|---|---|---|---|
| 1179-300 | 10-300mm/0.4-12" | ±0.06mm | 0.01mm/0.0005" |
| 1179-600 | 10-600mm/0.4-24" | ±0.07mm | 0.01mm/0.0005" |
| 1179-1000 | 15-1000mm/0.6-40" | ±0.09mm | 0.01mm/0.0005" |
| 1179-300WL | 10-300mm/0.4-12" | ±0.06mm | 0.01mm/0.0005" |
| 1179-600WL | 10-600mm/0.4-24" | ±0.07mm | 0.01mm/0.0005" |
