Gear Root Diameter Micrometers
Code: 3297
Measure diameter of gear root circle
Ratchet stop
Meet DIN863-3
Carbide measuring faces
Supplied with setting standards
Specification
| Code | Range | Accuracy | Graduation |
|---|---|---|---|
| 3297-100 | 5-100mm | 5μm | 0.01mm |
| 3297-200 | 100-200mm | 7μm | 0.01mm |
| 3297-300 | 200-300mm | 9μm | 0.01mm |
| 3297-400 | 300-400mm | 11μm | 0.01mm |
| 3297-500 | 400-500mm | 13μm | 0.01mm |
| 3297-600 | 500-600mm | 15μm | 0.01mm |
| 3297-700 | 600-700mm | 16μm | 0.01mm |
| 3297-800 | 700-800mm | 18μm | 0.01mm |
| 3297-900 | 800-900mm | 20μm | 0.01mm |
